STIHL batteries: Run times, charging times and compatibilities

With the right information, you can plan your work even more efficiently. Our interactive tool helps you with this. At the bottom of the page, you also find the charging times for all current STIHL batteries.

31.07.2026

Battery runtimes and compatibilities

Simply search for your STIHL battery-powered tool and discover all suitable battery combinations, including the respective runtimes per battery charge as well as further performance features.

Please refer to your product's user manual. These overviews show the current range of batteries and power tools. If you have any further questions, please contact STIHL or your STIHL dealer.

Working time or runtime?

In general usage, the German language refers to battery topics sometimes as “run times” and sometimes as “working times”. Therefore, STIHL uses these two terms identically without making any difference in content. Linguistic deviations from the printed catalog are therefore possible, but the time specifications are the same.

The ALLPRO battery system from STIHL: Next Level Power

The ALLPRO battery system is the further development of the previous AP system and sets new standards for your performance. More power, more efficiency and 100% compatible with your tools from the AP system. Service and maintenance for all your products from the AP system are also guaranteed in the long term by your STIHL dealer.

Discover the ALLPRO battery system

Battery charging times

The charging times of batteries do not only depend on their capacity – the charger also has an influence on the battery charging time. For example, the charging time for the STIHL AK 10 battery with the AL 101 charger is 95 minutes, while the battery is fully charged after only 45 minutes with the AL 300 charger. The following table shows which charger fits which STIHL battery and which charging time is required for a battery level of 80% and 100%.

	AL 1		AL 5		AL 5-2		LK 45		AL 101/ 101.1
	80%	100%	80%	100%	80%	100%	80%	100%	80%	100%
AS 2	60 min	80 min	30 min	50 min	30 min	50 min	-	-	-	-
BGA 45	-	-	-	-	-	-	210 min	300 min	-	-
HSA 45	-	-	-	-	-	-	145 min	210 min	-	-
FSA 45	-	-	-	-	-	-	145 min	210 min	-	-
AK 10	-	-	-	-	-	-	-	-	70 min	95 min
AK 20	-	-	-	-	-	-	-	-	135 min	180 min
AK 30 S	-	-	-	-	-	-	-	-	160 min	205 min
AP 20	-	-	-	-	-	-	-	-	125 min	160 min
AP 30	-	-	-	-	-	-	-	-	235 min	295 min
AP 100¹	-	-	-	-	-	-	-	-	75 min	100 min
AP 200/AP 200 S	-	-	-	-	-	-	-	-	150 min	200 min
AP 300	-	-	-	-	-	-	-	-	190 min	250 min
AP 300 S	-	-	-	-	-	-	-	-	230 min	300 min
AP 500 S	-	-	-	-	-	-	-	-	280 min	355 min
AR 1000¹	-	-	-	-	-	-	-	-	-	-
AR 2000¹	-	-	-	-	-	-	-	-	-	-
AR 3000¹	-	-	-	-	-	-	-	-	-	-
AR 2000 L	-	-	-	-	-	-	-	-	-	-
AR 3000 L	-	-	-	-	-	-	-	-	-	-
AP 20.1	-	-	-	-	-	-	-	-	115 min	150 min
AP 30.1	-	-	-	-	-	-	-	-	215 min	280 min
AP 100.0 P	-	-	-	-	-	-	-	-	80 min	110 min
AP 200.0 P	-	-	-	-	-	-	-	-	160 min	215 min
AP 300.0 P (C)	-	-	-	-	-	-	-	-	235 min	330 min

	AL 300		AL 301/ 301.1		AL 301-4		AL 500		AL 501		AL 1802 MO
	80%	100%	80%	100%	80%	100%	80%	100%	80%	100%	80 %²	100 %
AS 2	-	-	-	-	-	-	-	-	-	-	-	-
BGA 45	-	-	-	-	-	-	-	-	-	-	-	-
HSA 45	-	-	-	-	-	-	-	-	-	-	-	-
FSA 45	-	-	-	-	-	-	-	-	-	-	-	-
AK 10	30 min	45 min	25 min	40 min	-	-	30 min	45 min	25 min	40 min	-	-
AK 20	35 min	55 min	30 min	50 min	-	-	30 min	45 min	30 min	45 min	-	-
AK 30 S	35 min	60 min	35 min	60 min	-	-	35 min	50 min	-	-
AP 20	30 min	50 min	30 min	50 min	30 min	50 min	25 min	40 min	25 min	40 min
AP 30	60 min	80 min	60 min	80 min	60 min	80 min	35 min	50 min	35 min	50 min
AP 100¹	30 min	45 min	30 min	45 min	30 min	45 min	30 min	45 min	-	-
AP 200/AP 200 S	40 min	55 min	40 min	55 min	40 min	55 min	30 min	45 min	30 min	45 min
AP 300	45 min	60 min	50 min	75 min	50 min	75 min	25 min	35 min	25 min	35 min
AP 300 S	55 min	70 min	55 min	80 min	55 min	80 min	30 min	45 min	30 min	45 min
AP 500 S	70 min	90 min	70 min	90 min	70 min	90 min	40 min	55 min	40 min	55 min
AR 1000¹	130 min	160 min	-	-	-	-	90 min	120 min	-	-
AR 2000¹	190 min	215 min	-	-	-	-	100 min	130 min	-	-
AR 3000¹	220 min	265 min	-	-	-	-	120 min	160 min	-	-
AR 2000 L	210 min	270 min	235 min	295 min	235 min	295 min	120 min	160 min	120 min	160 min	90 min	125 min
AR 3000 L	325 min	410 min	340 min	425 min	340 min	425 min	175 min	230 min	185 min	235 min	95 min	135 min
AP 20.1	30 min	45 min	30 min	45 min	30 min	45 min	25 min	40 min	25 min	40 min	25 min	40 min
AP 30.1	55 min	75 min	55 min	75 min	55 min	75 min	30 min	45 min	30 min	45 min	30 min	45 min
AP 100.0 P	30 min	50 min	20 min	30 min	20 min	30 min	25 min	40 min	10 min	20 min	9 min	20 min
AP 200.0 P	30 min	45 min	40 min	60 min	40 min	60 min	30 min	45 min	20 min	35 min	9 min	20 min
AP 300.0 P (C)	55 min	70 min	60 min	90 min	60 min	90 min	30 min	45 min	30 min	50 min	9 min	20 min

_{¹no longer in the current product range
²Charging time up to 80% at ambient or pack temperatures of 25–40 °C in combination with AL 1802 MO; If 2 batteries are charged at the same time, the charging time may increase depending on the battery type
- Not recommended}
