AP Battery System: Battery Power for large gardens and professional use
The high-performance battery power tools in the AP system have been developed for professional use in landscaping, gardening and tree care.
31.07.2026
Pros and ambitious domestic users have been relying on the STIHL AP system for many years. Whether for lawn mowing, hedge trimming or sawing: you can handle all projects reliably, cost-effectively and with zero local emissions during operation. This is mainly due to the wide range of battery power tools and the modern lithium-ion technology. Even if the demands in everyday professional life are constantly growing - our battery technology is growing with it.
The ALLPRO battery system: maximum performance for your workday
The ALLPRO battery system is a further development of the previous AP system and sets new standards for performance. More power, more efficiency and 100% compatible with your AP system power tools. Service and maintenance for all your products from the AP system are also guaranteed for the long term by STIHL dealers.
| Feature | AP system | ALLPRO battery system |
|---|---|---|
| Area of use | Pros, ambitious domestic users | Pros, ambitious domestic users |
| Technology | Batteries with lithium-ion cells | Standard range: Batteries with lithium-ion cells Performance range: Batteries with tabless design |
| Voltage | 36 V | 40 V MAX |
| Peak power | Standard professional level | Up to 60% more power 1 |
| Charging time (80 %) | Standard high-speed charging | Up to 40% faster charging times 2 |
| Service life | up to 1,200 charge cycles | up to 3,000 charge cycles (+150%) 3 |
| Weatherproofing | IPX4 protection | IPX4 protection, IPX5 protection4 |
Discover all products from the ALLPRO system
AP System battery-powered tools
Your decision-making aids for the right battery system
The STIHL AP Battery System includes a wide range of high-performance battery-powered tools for large gardens and professional use. Powered by premium lithium-ion batteries, the system offers the flexibility to use the same batteries across compatible tools, with no compromise on their excellent performance and proven STIHL quality.
STIHL AP system batteries meet the highest safety standards and are always ready for use when needed thanks to intelligent energy and charging management.
Batteries in the AP system
Specifications of the batteries in the AP-System
| AP 20 | AP 30 | AP 200 S | AP 300 S | AP 500 S | |
|---|---|---|---|---|---|
| Battery weight | 1,3 kg | 1,8 kg | 1,3 kg | 1,8 kg | 2 kg |
| Energy content | 144 Wh1) | 270 Wh1) | 187 Wh1) | 281 Wh1) | 337 Wh1) |
| Max. power | ++ | +++ | ++ | +++ | ++++ |
| Equipment and function | - CONSTANT POWER POWER BOOST IPX4 LONG LIFE |
- CONSTANT POWER POWER BOOST IPX4 LONG LIFE |
STIHL CONNECTED CONSTANT POWER POWER BOOST IPX4 LONG LIFE |
STIHL CONNECTED CONSTANT POWER POWER BOOST IPX4 LONG LIFE |
STIHL CONNECTED CONSTANT POWER - IPX4 LONG LIFE |
1) Energy content according to the cell manufacturer's specification. To increase the service life, the energy content available in the actual application is lower.
The STIHL newsletter by pros for pros
Our STIHL Pro newsletter provides regular updates on everything there is to know about our high-performance products, services and events for pro users.
Important questions and answers
Tools from the STIHL AP system can be operated with both ALLPRO batteries and AP batteries. The AK system and ALLPRO system are not compatible with each other. An AK battery only fits in an AK power tool and an ALLPRO battery fits in all power tools from the previous AP system as well as in third-party power tools approved by STIHL.
Yes, service and support will remain in full effect. Your STIHL dealer will take care of your AP batteries, chargers and power tools as usual.
While the AK system is primarily for domestic use, the previous AP system offers maximum endurance for professional everyday use and demanding tasks around domestic gardens. The ALLPRO battery system is the upgrade for even more performance: The ALLPRO batteries with tabless battery technology deliver up to 60% 1 more peak power, 40% 2 faster charging times and up to 150% 3 longer service life with full compatibility with all power tools from the AP system.
1 Comparison with AP 300.0 P(C) and AP 300 S.
2 Time to reach 80% charge at ambient/battery temperatures of 25-40°C in combination with the AL 1802 MO. Valid for ALLPRO batteries AP 100.0 P, AP 200.0 P and AP 300.0 P(C).
3 Up to 3,000 cycles without noticeable loss of performance; can still be used afterwards. Only valid for ALLPRO batteries AP 100.0 P, AP 200.0 P and AP 300.0 P(C).
Lithium-ion batteries in the AK system are lightweight and handy, while those in the AP system are powerful and durable enough for professional tools.
For example: The AK 20 battery delivers 144 Wh battery energy at a weight of 1.2 kg, and belongs to the AK system. In contrast, the AP 300 S battery provides 281 Wh battery energy at a weight of 1.8 kg, and is in the AP system.
More about batteries
1 Comparison with AP 300.0 P(C) and AP 300 S.
2 Time to reach 80% charge at ambient/battery temperatures of 25-40°C in combination with the AL 1802 MO. Valid for ALLPRO batteries AP 100.0 P, AP 200.0 P and AP 300.0 P(C).
3 Up to 3,000 cycles without noticeable loss of performance; can still be used afterwards. Only valid for ALLPRO batteries AP 100.0 P, AP 200.0 P and AP 300.0 P(C).
4 IPX5 protection only applies to ALLPRO batteries AP 100.0 P, AP 200.0 P and AP 300.0 P(C). The ALLPRO AP 20.1 and AP 30.1 batteries are IPX4 certified.
