MS 150 TC-E - Extremely light 1.0 kW arborist chainsaw
Selection Arborist chainsaws

MS 150 TC-E

Extremely light 1.0 kW arborist chainsaw

General

MS150 TC-E
More pictures

Ideal for cutting back trees, professional pruning, limited crown reduction and working from a cherry picker. This lightweight champion of STIHL arborist saws delivers high cutting performance for its class with fine cut surfaces and has a good power-to-weight ratio. With ErgoStart as standard.

Versions

Price

* Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Product variations

Technical data

MS150 TC-E

Technical data

Displacement cm³ 23.6
Power output kW/bhp 1/1.3
Power-to-weight ratio kg/kW 2.6
Weight kg 1) 2.6
Sound pressure level dB(A) 2) 97
Sound power level dB(A) 2) 110
Vibration values left/right m/s² 3) 4.9/4.9
STIHL Oilomatic saw chain pitch/type 1/4" P PM3
Chain brake QuickStop
Oil tank volume cm3 150
Tank volume l 0.20

1) Without fuel, without bar and chain
2) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
3) K-factor according to DIR 2006/42/EC = 2m / s ²

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Features

MS150 TC-E

Standard features

  • Service-friendly air filter system Zoom
    Service-friendly air filter system

    The carburetor can be accessed without tools, so you can clean the air filter in a single step.

  • Fold-out hook Zoom
    Fold-out hook

    The fold-out hook serves as a carrying rope attachment for lowering the arborist saw and for security. When it is pushed in, the hook doesn't get in the way of your work or when it's in storage.

  • Advanced combustion technology Zoom
    Advanced combustion technology

    Four overflow channels swirl the fuel-air mix before ignition, allowing for optimum combustion and highly efficient performance. The result is lower fuel consumption and high torque across a broad rpm range.

  • Anti-vibration system Zoom
    Anti-vibration system

    Intense vibration at the handles of power tools can lead to long-term effects on blood vessels in the hands and arms. STIHL has therefore developed an effective anti-vibration system whereby the oscillations from the machine's engine are dampened which significantly reduces vibrations at the handles.

  • Compensator Zoom
    Compensator

    This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion mixture constant and hence also the engine power. The filter doesn't need to be cleaned until an appreciable drop in power occurs.

  • Manual fuel pump (Purger) Zoom
    Manual fuel pump (Purger)

    A small fuel pump delivers fuel to the carburettor at the touch of a button. This reduces the number of starting strokes required following extended breaks in operations.

  • Side chain tensioner Zoom
    Side chain tensioner

    The tensioning screw can be found on the side of the chain saw through the sprocket cover. This removes the need for contact with the sharp saw chain.

  • Ematic chain lubrication system Zoom
    Ematic chain lubrication system

    The Ematic chain lubrication system ensures pinpoint lubrication of the saw chain links and guide bar rails. When used with STIHL OILOMATIC saw chain, it will provide maximum lubrication, longer wear and less oil consumption than conventional methods of chain lubrication. The Ematic system can reduce bar oil consumption by up to 50%.

  • STIHL ErgoStart (E) Zoom
    STIHL ErgoStart (E)

    A genuine advance in easy starting. STIHL ErgoStart (E) cuts the effort required to start the tool by half, while the starter cord can be pulled at just one third of the normal force. All it takes is 2 fingers and a gentle pull action.

  • Tool free filler caps Zoom
    Tool free filler caps

    Special catches on the fuel and oil tanks for easy opening and locking without the need for tools.

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Accessories

MS150 TC-E

Accessories

    • HIFLEX Trousers, design C / class 2 Zoom
      HIFLEX Trousers, design C / class 2

      Chainsaw protection to EN 381-5, Class 2, Schoeller® ‘dryskin’ outer material, reinforced knee to ankle patches, 4 pockets, elasticated waist. STIHL HIFLEX protective clothing is designed to be lighter and more flexible than traditional protective clothing. With excellent breathable and water-resistant properties, this range is ideal for tree surgeons, arborists and anyone requiring lighter trousers. Design C.

    Technical data
    Cut protection type / class Design C / Class 2
    Fabric weight 210
    Size S-XXL
    UV protection factor 50+

    Versions

    Price
    • HIFLEX Trousers, design C / class 2, Size M, waist 30-34", leg 32" £270.00 *

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • 2-in-1 EasyFile Zoom
      2-in-1 EasyFile

      Practical tool for quickly sharpening the teeth and depth gauge in a single action, significantly reducing chain maintenance time. The sturdy frame allows for a smooth filing action with highly accurate results. All the files are easily replaceable. For 1/4" P, 3/8" P, .325", 3/8" and .404" saw chains. Includes round and flat files.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Rollomatic E Mini 1/4 Zoom
      Rollomatic E Mini 1/4"

      The combination of this particularly narrow guide bar with the 1/4" Picco chain (designed especially for cordless chainsaws and the MS 150 / MS150 T), offers considerable savings in weight coupled with improved cutting performance. Like all STIHL guide bars, it is made of high-grade chrome molybdenum steel.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Rollomatic E Mini 1/4 Zoom
      Rollomatic E Mini 1/4"

      The combination of this particularly narrow guide bar with the 1/4" Picco chain (designed especially for cordless chainsaws and the MS 150 / MS150 T), offers considerable savings in weight coupled with improved cutting performance. Like all STIHL guide bars, it is made of high-grade chrome molybdenum steel.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Picco Micro 3 (PM3), 1/4 Zoom
      Picco Micro 3 (PM3), 1/4" P 1.1 mm

      Exclusive to STIHL: This saw chain was specially designed for light, compact chainsaws and ensures less kickback and lower vibration levels. It combines exceptional cutting performance and quality with great user comfort. The 1/4" Picco chain features a flat and narrow design as well as the small chain pitch.

    Technical data
    Chain pitch 6.35mm/1/4"P
    Drive link thickness 1.1mm/.043"
    Required File size 3.2mm / 1/8"

    Versions

    Price
    • Picco Micro 3 (PM3), 1/4" P 1.1 mm 25 cm / 10", 56 drive links £16.50 *

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Picco Micro 3 (PM3), 1/4 Zoom
      Picco Micro 3 (PM3), 1/4" P 1.1 mm

      Exclusive to STIHL: This saw chain was specially designed for light, compact chainsaws and ensures less kickback and lower vibration levels. It combines exceptional cutting performance and quality with great user comfort. The 1/4" Picco chain features a flat and narrow design as well as the small chain pitch.

    Technical data
    Chain pitch 6.35mm/1/4"P
    Drive link thickness 1.1mm/.043"
    Required File size 3.2mm / 1/8"

    Versions

    Price
    • Picco Micro 3 (PM3), 1/4" P 1.1 mm 30 cm / 12", 64 drive links £18.76 *

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Filing kit Zoom
      Filing kit

      Includes file holder with round file, flat file and file gauge in a sturdy case.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • SynthPlus chain oil Zoom
      SynthPlus chain oil

      Semi synthetic high performance lubricant is made from high grade base oils (refined oils) which prevents resinification during prolonged downtimes. Outstanding protection against wear.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Rollomatic E Mini 1/4 Zoom
      Rollomatic E Mini 1/4"

      The combination of this particularly narrow guide bar with the 1/4" Picco chain (designed especially for cordless chainsaws and the MS 150 / MS150 T), offers considerable savings in weight coupled with improved cutting performance. Like all STIHL guide bars, it is made of high-grade chrome molybdenum steel.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • ADVANCE GTX trekking chainsaw boots Zoom
      ADVANCE GTX trekking chainsaw boots

      Special profile sole with very good grip. High quality, water-repellent suede. With breathable and waterproof GORE-TEX® membrane. Additional water and wear protection provided by high-rise rubber edge. Highly absorbent, removable inner sole. Suitable for demanding, professional chainsaw users on hillsides and for tree maintenance. EN ISO 17249, cut resistance Class 2 (= 24 m/s).

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

    • Combination socket tool Zoom
      Combination socket tool

      Practical tool for STIHL chainsaws. For adjusting the chain tension and changing the chain, bar and spark plugs.

    Versions

    Price

    * Manufacturer's recommended retail price updated as of February 2018 The manufacturer's recommended retail prices are subject to change without notice.

The version(s) available in each country may differ from the above range and specifications; specific details may be subject to change without notice. Please ask your local STIHL Approved Dealer for further information.

Documents

Owners manuals and safety brochures

STIHL MS 150 TC (GB) Download PDF, 1.9 MB

Notes:

  • STIHL and VIKING online owner’s manuals are usually for the latest versions of the machine. Your product may be a slightly older production model but the manual will still be appropriate for the relevant model number.
  • The languages ​​contained in the document are also displayed in brackets, for example (GB) = English.
